BLUETOOTH BEACON READER
* Read Range and Format
- READ RANGE 10cm -70meter Programmable
- BLUETOOTH BLE 4.0 BEACON
- iBEACONIOS V9.0)/BEACON(ANDROID V5.0)
- FIREBIRD APPS SUPPORT
OUTPUT
* 34Bit WIEGAND Output (Unique UUID)
* RS232 SERIAL Output (115,200bps)
* BARGATE Output (Max. 1A current)
* LOW BATTERY ALARM Output
INPUT
* OTR(One Time Reading) Control Input
* HOLD(Loop Sensor) Control Input
EASY INSTALLATION
* Direct Mount to 40x40mm Square Pole
ROBUST DESIGN
* SMART & WEATHERPROOF Design
* READER MODULE Fully Potted by Hard Epoxy

LONG RANGE READER
* Read Range
 - Max. 15m(LVO)/30m(LV1) with BMT2401 Tag
 - User Programmable Read Range(0.1m-30m)
* Operating Frequency
 - 2.4GHz ISM Band / Encrypted GFSK
OUTPUT
* 26Bit/34Bit WIEGAND Output
* RS232 SERIAL Output
* BARGATE Output(OC 1A for 1sec.)
* LOW BATTERY ALARM Output
INPUT
* OTR(One Time Reading) Control Input
* HOLD(Loop Sensor) Control Input
EASY INSTALLATION
* Direct Mount to 40x40mm Square Pole
ROBUST DESIGN
* SMART & WEATHERPROOF Design
* READER MODULE Fully Potted by Hard Epoxy

LONG RANGE CARD / TAG
* Read Range
 - Max. 15m(LV0) / 30m(LV1) at BMR2400 READER
* Operating Frequency
 - 2.4GHz ISM Band / Encrypted GFSK
* Encrypted Tag ID and Secure Protocols
* Wireless Programming ID Number (Contactless)
* 6 TX POWER LEVEL (LV0 ~ LV5)
* Ultra Low Power Consumption
* LOW BATTERY ALARM
* 3 Years Battery Lifetime
* Replaceable Battery (CR2025)

BLUETOOTH BEACON WRISTBAND TAG
* Bluetooth Beacon Read Range
- Up to 70m
Operating Frequency
- BLUETOOTH BLE 4.0
* Encypted UUID and Unique MacAddress
* Ultra Low Power Consumption
* 2 Years Battery Lifetime(@3sec.)
APPLICATIONS
* HANDS FREE ACCESS
* LOST & FOUND
* PERSONAL TRACKINGy
